R5 Arc Lock Model
P1.56 / 500*500MM / NationStarChange
Introducing
R5 Rental Curve Series
Curved Lock Design With Multiple Angle Adjustment
The Enbon R5 Rental Curve Series LED display features innovative curved lock design with 20% lighter weight than normal products. With ultra-thin 87mm panel thickness and flexible angle adjustment (0°/2.5°/5°/7.5°), it enables seamless splicing and creative installations for shows, conferences, and billboards.
Product Lines
Front & Rear Maintenance
It can be maintained from both front and back.
The R5 series features dual-sided maintenance capability, allowing easy access and service from both front and rear sides, significantly reducing maintenance time and improving operational efficiency.
Product Lines
Lighter Weight Easier Operation
20% lighter than normal products, making it more convenient to operate and move.
The R5 series is 20% lighter than standard products, with indoor cabinet weighing only 7.5kg and outdoor version at 8kg. This lightweight design makes transportation and installation significantly easier and more efficient.
Product Lines
Multiple Angles More Possibility
Provide a variety of splicing options to make your creativity unrestricted.
Each unit can be adjusted to multiple angles (0°/2.5°/5°/7.5°), enabling flexible curved installations. The curved lock design ensures seamless splicing between left and right cabinets, unlocking unlimited creative possibilities.
Product Lines
Built for excellence.
Every detail engineered to deliver performance that exceeds expectations.
High Refresh Rate & Grayscale
Refresh rate up to 7680Hz with 16-bit grayscale processing, delivering smooth and flicker-free display for crystal-clear video playback in any scenario.
Thinner Panels Lower Cost
Ultra-thin 87mm panel thickness. 6-in-1 flight case saves more space and transportation cost. 24 panels can be placed horizontally in a regular 20-foot or 40-foot truck.
Flexible Installation
Optional vertical installation and hanging beam installation. Suitable for stowing and hanging applications, perfect for shows, conferences, billboards and other scenes.
Product Lines
Specifications.
Precision engineering meets cutting-edge technology.
LED Lamp
SMD1212 / SMD1515 / SMD2121
Pixel Pitch
1.56mm / 1.95mm / 2.604mm / 2.976mm / 3.91mm
Brightness
650-1300 nits (Indoor) / 3500-4500 nits (Outdoor)
Refresh Rate
3840Hz / 7680Hz
Cabinet Weight
7.5 kg (Indoor) / 8 kg (Outdoor)
Cabinet Size
500×500×88mm
Module Size
250×250mm
Viewing Angle
H140° V140° (Outdoor)
Protection Rating
IP45 (Indoor) / IP65 (Outdoor)
Panel Thickness
87mm
Product Lines
Innovation in every detail.
Cutting-edge technology designed for perfection.
Curve Lock Design
Innovative curved lock mechanism enables seamless splicing between left and right cabinets, ensuring perfect alignment and stability for creative installations.
Fast Lock System
Quick-release fast lock mechanism allows rapid installation and disassembly, significantly reducing setup time for rental applications and events.
Multiple Angle Adjustment
Each unit can be adjusted to 0°/2.5°/5°/7.5° angles, providing flexible curved installation options to unlock unlimited creative possibilities.
Corner Cover & Power Box
Integrated corner cover design and optimized power box layout ensure clean aesthetics and reliable power distribution for seamless installations.
Front & Rear Maintenance
Dual-sided maintenance capability allows easy access from both front and back, reducing downtime and improving operational efficiency.
Product Lines
Performance that speaks.
Uncompromising quality in every aspect of operation.
87
Millimeter Thickness
Ultra-thin 87mm panel thickness. 6-in-1 flight case saves more space and transportation cost, with 24 panels fitting horizontally in a standard truck.
20%
Lighter Weight
20% lighter than normal products, making it more convenient to operate and move. Indoor cabinet weighs only 7.5kg, outdoor version at 8kg.
R5 Rental Curve Series.
Perfect for shows, conferences, billboards and other scenes. With curved lock design and multiple angle adjustment, it enables creative installations with seamless splicing and flexible configurations.
R5 Rental Curve Series
Curved Lock Design With Multiple Angle Adjustment
Product Lines
Designed for every scenario.
From rental stages to outdoor advertising.
Shows & Conferences
Exhibitions & Events
Perfect for shows, conferences, and exhibitions. The curved lock design with multiple angle adjustment enables creative curved installations and seamless splicing for stunning visual displays.
- Multiple angle adjustment (0°/2.5°/5°/7.5°)
- Curved lock seamless splicing
- Front & rear maintenance
Outdoor installations
Billboards & Advertising
High brightness up to 4500 nits (outdoor) ensures clear visibility under direct sunlight. IP65 protection rating and flexible installation options make it ideal for billboards and outdoor advertising displays.
- 3500-4500 nits brightness
- IP65 protection (outdoor)
- Vertical & hanging installation
Rental applications
Rental & Stage Productions
Ultra-thin 87mm panel and 20% lighter weight make transportation and setup significantly easier. 6-in-1 flight case design saves space and cost, perfect for rental companies and stage productions.
- 87mm ultra-thin panel
- 20% lighter weight
- 6-in-1 flight case
Product Lines
Why R5 Rental Curve Series?
Curved lock design with multiple angle adjustment, delivering flexible installation and seamless splicing for creative displays.
Premium Quality
ISO 9001 certified. 48-hour burn-in testing.
5-Year Warranty
Comprehensive coverage with on-site service.
24/7 Support
Global team. Under 2-hour response time.
Fast Delivery
Quick turnaround. Project management included.
Trusted by rental companies worldwide
Join rental companies and event organizers who have chosen R5 Rental Curve Series for its curved lock design, multiple angle adjustment, and exceptional flexibility for creative installations.
Rental Companies
•
Event Organizers
•
Stage Productions
•
Sports Venues
Ready to experiencecurved lock flexibility?
Get a personalized quote or schedule a live demonstration of our R5 Rental Curve Series LED display with multiple angle adjustment.
